| Material: |
Steel 45/SS416/SS420 /SS304/SS316 |
| Type: |
One shaft/Double-stem |
| Shape: |
Square |
|
Nominal Diameter |
Shaft Diameter |
Nominal Diameter |
Shaft Diameter |
||
|
2″ |
DN50 |
12.6 |
16″ |
DN400 |
33.15 |
|
2.5″ |
DN65 |
12.6 |
18″ |
DN450 |
38 |
|
3″ |
DN80 |
12.6 |
20″ |
DN500 |
41.15 |
|
4″ |
DN100 |
15.77 |
24″ |
DN600 |
50.65 |
|
5″ |
DN125 |
18.92 |
28″ |
DN700 |
50.65 |
|
6″ |
DN150 |
18.92 |
32″ |
DN800 |
63.35 |
|
8″ |
DN200 |
22.1 |
36″ |
DN900 |
75 |
|
10″ |
DN250 |
28.45 |
40″ |
DN1000 |
85 |
|
12″ |
DN300 |
31.6 |
48″ |
DN1200 |
105 |
|
14″ |
DN350 |
31.6 |
|
|
|
